Join two male BSPT threaded fittings at a 90-degree change of direction.

The Hansen Female Threaded Elbow has a female BSPT connection at both ends. It provides a right-angle connection between compatible male-threaded valves, fittings and pipework components.

Choose the correct size

Select the BSPT size that matches both male-threaded components. This is a female-to-female threaded elbow and does not connect directly to plain pipe.

Technical information

• Female BSPT x female BSPT connection
• 90-degree threaded elbow
• 16 bar rated variants are shown individually in the size selector.
• Suitable for cold-water systems up to 60°C.

About Hansen True Fit threaded fittings

• UV-stabilised, glass-fibre-reinforced nylon construction
• Heavy-duty tapered BSPT threads for a reliable seal
• Raw material approved for potable-water use
• Designed for water, irrigation, horticultural, agricultural, marine and plumbing applications
• Suitable for above- or below-ground pipework, provided the installation is correctly supported

Installation guidance

• Confirm the thread type, gender and size before fitting.
• Use a suitable thread sealing paste or tape on threaded joints.
• Do not overtighten: hand-tighten, then tighten a further one to two turns only.
• Do not install below driveways, paths or foundations.

Not suitable for swimming-pool or spa water with high chlorine concentrations.
