Join a male BSPT thread to a female BSPT thread at a 90-degree change of direction.

The Hansen Male/Female Threaded Elbow has one male and one female BSPT connection. It provides a compact right-angle connection between compatible threaded fittings, valves and pipework components.

Choose the correct size

Select the BSPT size needed for both sides of the connection. This fitting has one male and one female thread of the same size.

Technical information

• Male BSPT x female BSPT connection
• 90-degree threaded elbow
• 16 bar rated variants are shown individually in the size selector.
• Suitable for cold-water systems up to 60°C.

About Hansen True Fit threaded fittings

• UV-stabilised, glass-fibre-reinforced nylon construction
• Heavy-duty tapered BSPT threads for a reliable seal
• Raw material approved for potable-water use
• Designed for water, irrigation, horticultural, agricultural, marine and plumbing applications
• Suitable for above- or below-ground pipework, provided the installation is correctly supported

Installation guidance

• Confirm the thread type, gender and size before fitting.
• Use a suitable thread sealing paste or tape on threaded joints.
• Do not overtighten: hand-tighten, then tighten a further one to two turns only.
• Do not install below driveways, paths or foundations.

Not suitable for swimming-pool or spa water with high chlorine concentrations.
