Hunter G-85-B Full- or Part-Circle Golf Rotor

The Hunter G-85-B is a high-capacity block rotor for golf courses and large turf irrigation. It provides true full-circle or adjustable part-circle operation, with a stainless-steel riser and interchangeable standard- or low-angle nozzles.

Key specifications

• Arc: 60° to 360°
• Radius: 13.1 to 27.7 m
• Flow: 1.86 to 13.06 m³/h
• Operating pressure: 3.4 to 6.9 bar
• Pressure rating: 10 bar
• 1¼ in female ACME inlet
• Block check holds up to 2 m elevation difference
• Nozzle range: #10 to #53

Selection note: This is a block rotor without an integral control valve. Confirm nozzle trajectory and hydraulic duty for the intended location.
