Connect PE pipe to a male threaded fitting

This Plasson female adaptor creates a straight transition from metric PE water pipe to a male threaded valve, tap or fitting. It is suited to new installations, repairs and changes between metric pipe and BSP-style threaded components where the selected thread standard is compatible.

Selection guide

• PE pipe outside diameters: 16-110 mm
• Female thread options: 1/2-4 in
• Thread standard: ISO 7-1
• Body, nut and threaded section: polypropylene copolymer
• Grip ring: polyacetal
• Designed for water applications to ISO 17885

Select the variant by both the PE pipe outside diameter and the required female thread. Pressure rating and seal material vary across the size range, so confirm the chosen variant against the installation duty before fitting.
