Rain Bird 1¼ in BSP to ACME Swing Joint

An 18 in pre-assembled swing joint for positioning and connecting a compatible golf or large-turf rotor to the lateral pipework.

• Lay-arm diameter: 1¼ in
• Lay-arm length: 18 in / 45.7 cm
• Inlet: 1¼ in BSP
• Outlet: 1¼ in modified ACME
• Rigid PVC Type I construction
• Double O-ring seals at rotating joints
• Pressure rating: 21.7 bar at 22.8°C

Installation

Match both thread types to the service tee and rotor before ordering. Use a suitable seal on the BSP connection; the modified ACME connection seals with its O-ring. Hand-tighten threaded components and fully depressurise the system before adjusting or removing the rotor.
