These LV6200A two-piece full-bore ball valves provide quarter-turn isolation through female BSPP connections. The stainless-steel body, ball and stem are paired with PTFE seats and seals.

Key specifications

• Sizes listed: ½ in, ¾ in, 1 in, 1½ in and 2 in
• Female x female BSPP connections
• Full-bore, two-piece construction
• 1.4408 / CF8M stainless-steel body and ball, with AISI 316 stem
• PTFE seats and seals
• Anti-blowout stem and locking provision
• Pressure class: PN63
• Published temperature range: -29°C to 180°C

Select the same nominal size at both ends. Confirm fluid compatibility and the pressure rating at the intended temperature before installation. Isolate and depressurise the line, use a suitable thread-sealing method and hold the valve body correctly while tightening to avoid installation strain.
